Compact Size
		Double Output
			Anti Rotation
				Low Deviation High Precision
					Built -In Magnet

Standard Type - DPCO Series

Model	Bore Size mm	Rod Size mm	Theoretical Thrust kgf	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
DPCO 10	10	6	7.85	100 ~ 500	1.5 ~ 7.0 (Air)	0.OC ~ 60OC	10 ~ 100
DPCO 16	16	8	20.10				10 ~ 200
DPCO 20	20	10	31.40				10 ~ 250
DPCO 25	25	12	49.10
DPCO 32	32	16	80.40

Download Acrobat Reader for open PDF file

Slide Unit Type - DPCS Series

Model	Bore Size mm	Rod Size mm	Theoretical Thrust kgf	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
DPCS 10 (Stop production)	10	6	5.05	50 ~ 200	1.5 ~ 9.0 (Air)	0.OC ~ 60OC	25 ~ 100
DPCS 16	16	8	15.10				25 ~ 200
DPCS 20	20	10	23.55				25 ~ 250
DPCS 25	25	12	37.80
DPCS 32	32	16	60.30

Download Acrobat Reader for open PDF file
