Save 1/2 Working Space
		Magnetic Coupled Design
			Sealed, No Leakage
				Various Type Choices
					High Weight Loading

Monoblock Type - MFCP Series

Model	Bore Size mm	Theoretical Thrust kgf	Holding Force kgf	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
MFCP 20	20	15.7	45	100 ~ 500	2.0 ~ 7.0 (Air)	0.OC ~ 60OC	100 ~ 600
MFCP 25	25	24.55	69				100 ~ 600
MFCP 32	32	40.2	110				200 ~ 1000

Download Acrobat Reader for open PDF file

Guide Type - MFCG Series

Model	Bore Size mm	Theoretical Thrust kgf	Holding Force kgf	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
MFCG 20	20	15.7	45	100 ~ 500	2.0 ~ 7.0 (Air)	0.OC ~ 60OC	100 ~ 600
MFCG 25	25	24.55	69				100 ~ 600
MFCG 32	32	40.2	110				200 ~ 1000

Download Acrobat Reader for open PDF file

Monoblock With Supporting Type - MFCH Series

Model	Bore Size mm	Theoretical Thrust kgf	Holding Force kgf	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
MFCH 20	20	15.7	45	100 ~ 500	2.0 ~ 7.0 (Air)	0.OC ~ 60OC	500 ~ 1500
MFCH 25	25	24.55	69				500 ~ 1500

Download Acrobat Reader for open PDF file
