Module Design
		Compact Size
			Anti Rotation
				Low Deviation High Precision
					Various Type Choices
						Built - In Magnet

Standard Type - TRCO Series

Model	Bore Size mm	Theoretical Thrust kgf	Non- Rotation	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
TRCO 32	32	40.20	L : 0.08O M : 0.06O	100 ~ 500	1.5 ~ 10.2 (Air)	0.OC ~ 60OC	25 ~ 250
*TRCO 40	40	62.85
*TRCO 50	50	98.15

Adjustable Stroke Type - TRCA Series

Model	Bore Size mm	Theoretical Thrust kgf	Non- Rotation	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
TRCA 32	32	40.20	L : 0.08O M : 0.06O	100 ~ 500	1.5 ~ 10.2 (Air)	0.OC ~ 60OC	25 ~ 250
*TRCA 40	40	62.85
*TRCA 50	50	98.15

Slide Unit Type - TRCS Series

Model	Bore Size mm	Theoretical Thrust kgf	Non- Rotation	Speed Range mm / s	Pressure Range kgf / cm2	Temperature	Standard Stroke mm	Download PDF
TRCS 32	32	40.20	L : 0.08O M : 0.06O	100 ~ 500	1.5 ~ 10.2 (Air)	0.OC ~ 60OC	25 ~ 250
*TRCS 40	40	62.85
*TRCS 50	50	98.15
